Lecture 9 – Grouping on Multiple Columns, Merging

DSC 10, Fall 2024

Announcements

• There is no quiz or course meeting this afternoon.
• Lab 2 is due tomorrow at 11:59PM.
• Homework 2 is due Sunday at 11:59PM.
• The Midterm Project is coming out soon. Try to find a partner!👯‍♀️
  • Working with a partner is optional but highly recommended. You can work with a partner from any lecture section.
  • You must follow these project partner guidelines. In particular, make sure to work together on all parts of the project, not split up the project and each do half.

Agenda

• Grouping on multiple columns.
• Merging.

Grouping on multiple columns

DSC 10 student data

roster = bpd.read_csv('data/roster-anon.csv')
roster

	name	section
0	Jacob Rrrkga	10AM
1	Steven Dhixba	10AM
2	Rundong Qphuob	9AM
...	...	...
439	Shreyesh Tlbgcn	1PM
440	Sally Tthnjf	10AM
441	Lawrence Zdeaft	10AM

442 rows × 2 columns

Recall, last class, we extracted the first name of each student in the class.

def first_name(full_name):
    '''Returns the first name given a full name.'''
    return full_name.split(' ')[0]

roster = roster.assign(
    first=roster.get('name').apply(first_name)
)
roster

	name	section	first
0	Jacob Rrrkga	10AM	Jacob
1	Steven Dhixba	10AM	Steven
2	Rundong Qphuob	9AM	Rundong
...	...	...	...
439	Shreyesh Tlbgcn	1PM	Shreyesh
440	Sally Tthnjf	10AM	Sally
441	Lawrence Zdeaft	10AM	Lawrence

442 rows × 3 columns

How many students named Ryan are in each section?

We discovered that Ryan was the most popular first name overall.

name_counts = (
    roster
    .groupby('first')
    .count()
    .sort_values('name', ascending=False)
    .get(['name'])
)
name_counts

	name
first
Ryan	9
Kyle	5
Matthew	4
...	...
Isabela	1
Isabel	1
Zonglin	1

382 rows × 1 columns

To find the number of 'Ryan's in each lecture section, we can query for only the rows corresponding to 'Ryan's, and then group by 'section'.

roster[roster.get('first') == 'Ryan'].groupby('section').count()

	name	first
section
10AM	4	4
1PM	4	4
9AM	1	1

But what if we want to know the number of 'Kyle's and 'Matthew's per section, too?

roster[roster.get('first') == 'Kyle'].groupby('section').count()

	name	first
section
10AM	3	3
1PM	1	1
9AM	1	1

roster[roster.get('first') == 'Matthew'].groupby('section').count()

	name	first
section
1PM	3	3
9AM	1	1

Is there a way to do this for all first names and sections all at once?

How many students with each first name does each lecture section have?

• Right now, we can count the number of students with each first name, by grouping roster by 'first'.

# One row per unique first name.
roster.groupby('first').count().get('name')

first
Aaditya     1
Aarman      1
Aayush      1
           ..
Zhongyan    1
Zihan       1
Zonglin     1
Name: name, Length: 382, dtype: int64

• We can also count the number of students in each lecture section, by grouping roster by 'section'.

# One row per unique section.
roster.groupby('section').count().get('name')

section
10AM    146
1PM     149
9AM     147
Name: name, dtype: int64

• However, neither of the above Series give us the number of students with each first name in each section.
  • For instance, neither result tells me the number of 'Ryan's in the 9AM section or the number of 'Kyle's in the 10AM section.

• It would be nice if we could group by both 'first' and 'section' – and we can!

Grouping on multiple columns

roster

	name	section	first
0	Jacob Rrrkga	10AM	Jacob
1	Steven Dhixba	10AM	Steven
2	Rundong Qphuob	9AM	Rundong
...	...	...	...
439	Shreyesh Tlbgcn	1PM	Shreyesh
440	Sally Tthnjf	10AM	Sally
441	Lawrence Zdeaft	10AM	Lawrence

442 rows × 3 columns

We can pass a list of column names to .groupby!

roster.groupby(['section', 'first']).count()

		name
section	first
10AM	Aidan	1
	Aileen	1
	Alice	1
...	...	...
9AM	Yifei	1
	Yra	1
	Yuhan	1

412 rows × 1 columns

The above DataFrame is telling us, for instance, that there is 1 student with the first name 'Aidan' in the 10AM section.

It is not saying that there is only one 'Aidan' in the course overall. There could be more in the other sections.

Grouping on multiple columns

• To group on multiple columns, pass a list of column names to .groupby:

df.groupby(['col_1', 'col_2', ..., 'col_k'])

• Group by 'col_1' first. Within each group, group by 'col_2', and so on.

• Important: The resulting DataFrame has one row per unique combination of entries in the specified columns.
  • On the previous slide, we had exactly one row for every combination of 'section' and 'first'.

• Formally, when we group on multiple columns, we are creating subgroups – that is, groups within groups.
  • On the previous slide, we first grouped by 'section', and within each section, we grouped by 'first'.

Notice the index... 🤔

• This is called a "MultiIndex".
  • The DataFrame is indexed by 'section' and 'first'.
• We won't worry about the details of MultiIndexes.
• We can use .reset_index() to "flatten" our DataFrame back to normal.

roster.groupby(['section', 'first']).count().reset_index()

	section	first	name
0	10AM	Aidan	1
1	10AM	Aileen	1
2	10AM	Alice	1
...	...	...	...
409	9AM	Yifei	1
410	9AM	Yra	1
411	9AM	Yuhan	1

412 rows × 3 columns

Does order matter?

roster.groupby(['section', 'first']).count().reset_index()

	section	first	name
0	10AM	Aidan	1
1	10AM	Aileen	1
2	10AM	Alice	1
...	...	...	...
409	9AM	Yifei	1
410	9AM	Yra	1
411	9AM	Yuhan	1

412 rows × 3 columns

roster.groupby(['first', 'section']).count().reset_index()

	first	section	name
0	Aaditya	9AM	1
1	Aarman	1PM	1
2	Aayush	1PM	1
...	...	...	...
409	Zhongyan	10AM	1
410	Zihan	1PM	1
411	Zonglin	10AM	1

412 rows × 3 columns

Answer: Kind of. The order of the rows and columns will be different, but the content will be the same.

Activity

Using counts, find the lecture section with the most 'Kevin's.

✅ Click here to see the solution after you've tried it yourself.

kevin_counts = counts[counts.get('first') == 'Kevin']
kevin_counts.sort_values('name', ascending=False).get('section').iloc[0]

counts = roster.groupby(['section', 'first']).count().reset_index()
counts

	section	first	name
0	10AM	Aidan	1
1	10AM	Aileen	1
2	10AM	Alice	1
...	...	...	...
409	9AM	Yifei	1
410	9AM	Yra	1
411	9AM	Yuhan	1

412 rows × 3 columns

Activity

Using counts, find the longest first name in the class that is shared by at least two students in the same section.

✅ Click here to see the solution after you've tried it yourself.

with_len = counts.assign(length=counts.get('first').apply(len))
with_len[with_len.get('name') >= 2].sort_values('length', ascending=False).get('first').iloc[0]

...

Ellipsis

Example: Sea temperatures 🌊

This dataset contains the sea surface temperature in La Jolla, on many days ranging from August 22, 1916 to June 30, 2023.

sea_temp = bpd.read_csv('data/sea_temp.csv')
sea_temp

	YEAR	MONTH	DAY	SURFACE_TEMP
0	1916	8	22	19.5
1	1916	8	23	19.9
2	1916	8	24	19.7
...	...	...	...	...
37738	2023	6	28	19.7
37739	2023	6	29	19.3
37740	2023	6	30	20.6

37741 rows × 4 columns

Concept Check ✅ – Answer at cc.dsc10.com

We want to find the single month (e.g. November 1998) with the highest average 'SURFACE_TEMP'.

Which of the following would help us achieve this goal?

A. sea_temp.groupby('SURFACE_TEMP').mean()

B. sea_temp.groupby('MONTH').mean()

C. sea_temp.groupby(['YEAR', 'MONTH']).mean()

D. sea_temp.groupby(['MONTH', 'DAY']).mean()

E. sea_temp.groupby(['MONTH', 'SURFACE_TEMP']).mean()

...

Ellipsis

Plots of monthly and yearly average surface temperature 📈

(sea_temp
 .groupby('MONTH')
 .mean()
 .plot(kind='line', y='SURFACE_TEMP')
);

# Why is there a sudden drop at the end? Look at the dates of data collection!
(sea_temp
 .groupby('YEAR')
 .mean()
 .plot(kind='line', y='SURFACE_TEMP')
);

Summary: Grouping on multiple columns

• Pass a list of columns to .groupby to group on multiple columns. This creates groups within groups.
• Use .reset_index() after grouping on multiple columns to move the MultiIndex back to the columns.

Merging 🚙

offer_percentage = bpd.DataFrame().assign(
    clothing_type=['Shirt', 'Pants', 'Dress', 'Shorts', 'Shoes'],
    offer_percentage=[20, 30, 50, 30, 50]
)

clothes = bpd.DataFrame().assign(
    item=['Dress', 'Shirt', 'Shoes', 'Pants', 'Shoes'],
    retail_price=[150, 30, 90, 50, 70]
)

Example: Clothing Resale 👕

# The percentage of retail price that I can earn for reselling my clothes.
offer_percentage

	clothing_type	offer_percentage
0	Shirt	20
1	Pants	30
2	Dress	50
3	Shorts	30
4	Shoes	50

# The items I want to sell and their retail prices.
clothes

	item	retail_price
0	Dress	150
1	Shirt	30
2	Shoes	90
3	Pants	50
4	Shoes	70

• Question: If I sell all of the clothes in my collection, how much will I earn?

• Issue: The information I need to answer the question is spread across multiple DataFrames.

If I sell all of the clothes in my collection, how much will I earn?

clothes_merged = offer_percentage.merge(clothes, left_on='clothing_type', right_on='item')
clothes_merged

	clothing_type	offer_percentage	item	retail_price
0	Shirt	20	Shirt	30
1	Pants	30	Pants	50
2	Dress	50	Dress	150
3	Shoes	50	Shoes	90
4	Shoes	50	Shoes	70

What just happened!? 🤯

# Click through the presentation that appears.
merging_animation()

.merge

To "merge" two DataFrames:

• Pick a "left" and "right" DataFrame.
• Choose a column from each to "merge on".

left_df.merge(
    right_df,
    left_on='left_col_name',
    right_on='right_col_name'
)

• left_on and right_on should be column names (they don't have to be the same).
• The resulting DataFrame contains a single row for every match between the two columns.
• Rows in either DataFrame without a match disappear!

If I sell all of the clothes in my collection, how much will I earn?

clothes_merged = offer_percentage.merge(clothes, left_on='clothing_type', right_on='item')
clothes_merged

	clothing_type	offer_percentage	item	retail_price
0	Shirt	20	Shirt	30
1	Pants	30	Pants	50
2	Dress	50	Dress	150
3	Shoes	50	Shoes	90
4	Shoes	50	Shoes	70

# If I sell all of the clothes in my collection, how much will I earn?
(clothes_merged.get('offer_percentage') / 100 * clothes_merged.get('retail_price')).sum()

176.0

Does it matter which DataFrame is the left or right DataFrame? 🤔

offer_percentage.merge(clothes, left_on='clothing_type', right_on='item')

	clothing_type	offer_percentage	item	retail_price
0	Shirt	20	Shirt	30
1	Pants	30	Pants	50
2	Dress	50	Dress	150
3	Shoes	50	Shoes	90
4	Shoes	50	Shoes	70

clothes.merge(offer_percentage, left_on='item', right_on='clothing_type')

	item	retail_price	clothing_type	offer_percentage
0	Dress	150	Dress	50
1	Shirt	30	Shirt	20
2	Shoes	90	Shoes	50
3	Shoes	70	Shoes	50
4	Pants	50	Pants	30

Answer: The order of the rows and columns will be different, but the content will be the same.

Special cases

What if the names of the columns we want to merge on are both the same?

Instead of using left_on='col' and right_on='col', you can just say on='col'.

offer_percentage

	clothing_type	offer_percentage
0	Shirt	20
1	Pants	30
2	Dress	50
3	Shorts	30
4	Shoes	50

clothes_relabeled = clothes.assign(clothing_type=clothes.get('item')).drop(columns=['item'])
clothes_relabeled

	retail_price	clothing_type
0	150	Dress
1	30	Shirt
2	90	Shoes
3	50	Pants
4	70	Shoes

In this example, the column we want to merge on in both DataFrames is named 'clothing_type', so we can just use on='clothing_type'.

offer_percentage.merge(clothes_relabeled, on='clothing_type')

	clothing_type	offer_percentage	retail_price
0	Shirt	20	30
1	Pants	30	50
2	Dress	50	150
3	Shoes	50	90
4	Shoes	50	70

Notice: There's only one column containing the type of clothing now.

What if we want to merge using an index instead of a column?

Instead of using left_on or right_on, use left_index=True or right_index=True.

offers_by_item = offer_percentage.set_index('clothing_type')
offers_by_item

	offer_percentage
clothing_type
Shirt	20
Pants	30
Dress	50
Shorts	30
Shoes	50

clothes

	item	retail_price
0	Dress	150
1	Shirt	30
2	Shoes	90
3	Pants	50
4	Shoes	70

In this example, we want to merge using the index in the left DataFrame (offers_by_item) and the item column in the right DataFrame (clothes).

offers_by_item.merge(clothes, left_index=True, right_on='item')

	offer_percentage	item	retail_price
1	20	Shirt	30
3	30	Pants	50
0	50	Dress	150
2	50	Shoes	90
4	50	Shoes	70

Activity setup

nice_weather_cities = bpd.DataFrame().assign(
    city=['La Jolla', 'San Diego', 'Austin', 'Los Angeles'],
    state=['California', 'California', 'Texas', 'California'],
    today_high_temp=['79', '83', '87', '87']

)

schools = bpd.DataFrame().assign(
    name=['UCSD', 'University of Chicago', 'University of San Diego','Johns Hopkins University', 'UT Austin', 'SDSU', 'UCLA'],
    city=['La Jolla', 'Chicago', 'San Diego', 'Baltimore', 'Austin', 'San Diego', 'Los Angeles'],
    state=['California', 'Illinois', 'California', 'Maryland', 'Texas', 'California', 'California'],
    graduation_rate=[0.87, 0.94, 0.78, 0.92, 0.81, 0.83, 0.91 ]
)

Concept Check ✅ – Answer at cc.dsc10.com

Without writing code, how many rows are in nice_weather_cities.merge(schools, on='city')?

A. 4    B. 5    C. 6    D. 7    E. 8

nice_weather_cities

	city	state	today_high_temp
0	La Jolla	California	79
1	San Diego	California	83
2	Austin	Texas	87
3	Los Angeles	California	87

schools

	name	city	state	graduation_rate
0	UCSD	La Jolla	California	0.87
1	University of Chicago	Chicago	Illinois	0.94
2	University of San Diego	San Diego	California	0.78
3	Johns Hopkins University	Baltimore	Maryland	0.92
4	UT Austin	Austin	Texas	0.81
5	SDSU	San Diego	California	0.83
6	UCLA	Los Angeles	California	0.91

Followup activity

Without writing code, how many rows are in nice_weather_cities.merge(schools, on='state')?

nice_weather_cities

	city	state	today_high_temp
0	La Jolla	California	79
1	San Diego	California	83
2	Austin	Texas	87
3	Los Angeles	California	87

schools

	name	city	state	graduation_rate
0	UCSD	La Jolla	California	0.87
1	University of Chicago	Chicago	Illinois	0.94
2	University of San Diego	San Diego	California	0.78
3	Johns Hopkins University	Baltimore	Maryland	0.92
4	UT Austin	Austin	Texas	0.81
5	SDSU	San Diego	California	0.83
6	UCLA	Los Angeles	California	0.91

nice_weather_cities.merge(schools, on='state')

	city_x	state	today_high_temp	name	city_y	graduation_rate
0	La Jolla	California	79	UCSD	La Jolla	0.87
1	La Jolla	California	79	University of San Diego	San Diego	0.78
2	La Jolla	California	79	SDSU	San Diego	0.83
...	...	...	...	...	...	...
10	Los Angeles	California	87	SDSU	San Diego	0.83
11	Los Angeles	California	87	UCLA	Los Angeles	0.91
12	Austin	Texas	87	UT Austin	Austin	0.81

13 rows × 6 columns

nice_weather_cities.merge(schools, on='state').shape[0]

13

More practice!

Here are related exam problems to help you practice merging:

• Problem 5 from the Fall 2021 midterm.
• Problem 7 from the Fall 2022 midterm.

Summary, next time

Summary

• To group on multiple columns, pass a list to .groupby.
  • The result has one row for every unique combination of elements in the specified columns.
• To combine information from multiple DataFrames, use .merge.
  • When using .merge, Python searches for a match between a specified column in each DataFrame and combines the rows with a match.
  • If there are no matches, the row disappears!

Next time

• if-statements, to execute code only when certain conditions are met.
• for-loops, to repeat code many times.
• Both are foundational programming tools. 🛠
